low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm
  • low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm

low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm

3.7~4.0 USD
Min. Order:
1000 Square Meter
Trade Term:
FOB,CFR,CIF,DDP,EXW
Payment Terms:
L/C, T/T
Place of Origin:
Zhejiang, China (Mainland)
Means of Transport:
Ocean
Production Capacity:
300000 Square...
Packing:
100 pcs packed in one pallet
Delivery Date:
within 15 days after...
Type:
Flat Panel
Pipe Material:
Glass
Application:
solar panel solar collector,LED light
Brand Name:
DK
Light transmitance:
91%-98% Light transmitance
Thickness:
3.2mm
Video:
video

  • Product Description
  • Related Products
  • Related Links
  • Low iron tempered solar glass for solar panel in manufacturer 3.2mm 4mm

    Description:

    Solar Glass, is a high performance low iron glass with very high solar energy transmittance. When toughened, its strength and durability make it the ideal choice for crystalline silicon photovoltaic application as well as for solar thermal collectors.

    Features:

    *Ultra high solar energy transmittance and low light reflectance.

    *Choice of patterns, to suit the specific application.

    *The pyramidal patterns can assist in the laminating process during module manufacture, but can be used on the external surface if desired.

    *Prismatic/Matte product available with Anti-Reflective (AR) coating for optimal solar energy conversion.

    *Available in fully tempered/toughened form to provide excellent strength with resistance to hail, mechanical impact and thermal stress.

    *Easily to be cut, coated and tempered.



    Specification:



    Technical Data:

    Thickness: 3.2mm, 4mm

    Further process: cleaning, cutting, rough grinding, hole, etc.

    Surface: mistlite single pattern, the pattern shape can be made by your request.

    Visible Light Transmittance: 91.60%

    Visible Light Reflectance: 7.30%

    Solar Transmittance: 92%

    Solar Reflectance: 7.40%

    UV Transmittance: 86.80%

    Total Solar Heat Gain Coefficient: 92.20%

    Shading Coefficient: 1.04%

    Performance varied due to different thickness

    Usage: It is widely used as solar power generator, water heater .Solar modules in China.

    Packing:Powder or paper interred between the glass; Packed by strong sea worthy wooden crates.



    Product nameTempered Low Iron  Solar Glass

    Surface

    mistlite single pattern, the pattern shape can be made by your request.

    Dimension Tolerance(mm)

    ±1.0

    Surface Condition

    Structured in same way on both sides acc. To technical requirement

    Solar transmittance

    91.6%

    Iron Content

    100ppm

    Poisson's ratio

    0.2

    Density

    2.5g/cc

    Young's Modulus

    73GPa

    Tensile strength

    90N/mm2

    Compressive Strength

    700-900N/mm2

    Expansion coefficient

    9.03 x  10-6/

    Softening point(C)

    720

    Annealing point(C)

    550

    Type

    1. Ultra-Clear solar glass

    2. Ultra-Clear patterned solar glass (widely used), above 90% customers need this product.

    3. Single AR coating solar glass
