Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire

Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire

12.0 USD
Min. Order:
10 Kilogram
Trade Term:
FOB,CFR,CIF,EXW
Payment Terms:
L/C, T/T, WU
Place of Origin:
Zhejiang, China (Mainland)
Means of Transport:
Ocean, Air
Production Capacity:
3T one day
Packing:
paper carton with...
Delivery Date:
3-15 days after...
Type:
soldering ribbon
Pipe Material:
Copper
Application:
Solar Thermal
Brand Name:
DK
SIZE:
1.3*0.2MM
Materials:
Copper wire coated by tin
Customized:
Customized is available

  • Product Description
  • Related Products
  • Related Links
  • Solar Panel Raw Materials PV ribbons bus bar solar panel tabbing wire

    About PV Ribbon:

    PV ribbon is composed of Copper and coating alloys, and divided into Tabbing Ribbon and Bus bar ribbon.

    • Tabbing Ribbon: it is commonly connects the positive and negative sides of the cells in series.

    • Bus bar Ribbon: it is concentrate the cell stringing into junction box and channels electrical current.

    • Product Description

      Features and Applications:

      The item (tin coated copper welding ribbon) is based on size of Width*Thickness: 1.3*0.23 mm (it also can be 1.5-2.5mm * 0.08-0.25mm as your option),

      sale as per lot, 2kgs/lot.

      if you want buy more or less quantity, pls contact us, we will correct the price and freight cost for you.



      1) welding ribbon for big power solar panel:

      Copper baseelectrician Park copper (TR line) rolling or T2 copper tape slitting
      Copper substrate resistivityρ ≤ 0.0172Ωmm2 / m
      Solder Composition62% Sn36% Pb2% Ag; 60% Sn40% Pb; 96.5% Sn3.5% Ag (Bi optional)
      The thickness of the tin layer10μm-40μm, sided uniform
      Thickness deviation≤ 0.008
      Width deviationthe rolled products ≤ 0.1mm; slitting Commodities ≤ 0.005mm
      Elongationthe soft state ≥ 20%; semi-soft state ≥ 15%
      Specificationswidth 1.5mm-2.5mm; thickness 0.08mm-0.25mm. (here is 1.5*0.2 mm)
      Packagingcardboard, " I shape" wheel, box
      Suitable for DIY solar cell and solar panel, also suitable for machine automatic welding middle without decapitation; crop for customers Length carton packaging


      2) welding ribbon for epoxy solar panel etc. mini solar panel:



      3) Bus-bar for big power solar panel:
