HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL
  • HOT SELL 250W POLY SOLAR PANEL

HOT SELL 250W POLY SOLAR PANEL

100.0 USD
Min. Order:
350 Piece/Pieces
Payment Terms:
T/T
Place of Origin:
Zhejiang, China (Mainland)
Means of Transport:
Ocean
Production Capacity:
2*40HQ one day
Packing:
2 pcs one carton
Delivery Date:
10-15 days after...
Application:
Solar Thermal
Type:
Flat Panel
Pipe Material:
Others
Brand Name:
DK
size:
1640*992*40mm
weight:
18kgs
number of cell:
60
certificate:
TUV
solar cell size:
156.75*156.75mm cell
warranty:
25years 80% output
frame:
Aluminium frame
Video:
video

  • Product Description
  • Related Products
  • Related Links
  • HOT SELL 250W POLY SOLAR PANEL

    HOT SELL 250W POLY SOLAR PANEL

    • Industry leading module power output warranty

    • International quality, safety and performance  certifications

    • High-reliability

    • Manufacturing facility certified to ISO9001 Quality Management System standards

    • Beautiful appearance,good durability&easy installation

    • Special design in accordance with requirements of customers

    Typical Type

    250W
    Max-Power (Pmax) :250W
    Max-Power Current (Vmp) 30.39
    Max-Power Current (Imp) 8.23
    Open-Circuit Voltage(Voc)36.97
    Short-Circuit Current (Isc)9.29
    Max-System VoltageDC1000V(TUV)/600V(UL)
    Cell effciency (%)17.6
    Module effciency (%)15.4


    HOT SELL 250W POLY SOLAR PANEL

    MECHANICAL DATA

    Dimensions:1640*992*40mm
    Weight:18kgs
    Front Glass:3.2 mm tempered glass
    Output Cables:

    TUV (2Pfg1169:2007)

    4mm2 ,symmetrical lengths,900 mm

    Connectors:MC4 compatible IP67
    cell type

    Poly Crystalline silicon

    ,156.75*156.75mm

    Number of cells:

    60 cells in series


    TEMPERAT URE CHARACTERISTICS

    Temp.Coeff.of Isc(TK Isc):0.045% / ℃

    Temp.Coeff.of Voc(TK Voc):(-0.34%) /℃

    Temp.Coeff of Pmax(TK Pmax):(-0.47%) /℃

    Operating Temperature:(-40~+85)℃

    Nominal Operating Cell Temperature : 45 ± 2 ℃

    PACKING CONFIGURATION

    Container

    20'GP
    40'GP40'HQ

    Pcs per Pallet


    464656

    Pallets Qty

    61414

    Container Qty

    276644
    784
    HOT SELL 250W POLY SOLAR PANEL

    TESTS, CERTIFICATI ONS AND WARRANTIES

    Standard tests

    IEC 61215, IEC 61730



    System certs

    ISO 9001, ISO 14001



    Certifications

    TUV, CE, MCS, PV CYCLE,CEC ,CHUBB



    Extreme wind and  snow loads testing



    withstand extreme wind (3800 Pascal) and snow loads (5400 Pascal)



    Tolerance



    ±3%



    Junction Box



    ≥ IP65 Rated


    Warranties



    10-year material and workmanship

    and 25-year output at least 80%.
